This is next level technology - and the BendTron is a first generation master piece driven completely by electrical motors.



The BendTron is available for lengths varying from 4 ~ 15 meters and material thickness of upto 1.5mm steel.

​

​

Computer-operated back gauge fingers enable the simple and precise positioning of sheet metals. The back gauge fingers hereby drive automatically into the correct position with each new bending phase. All back gauge fingers can be freely positioned over the entire bending length for optimal adjustment to the workpiece. Thanks to the freely positionable foot switch, both hands remain free when fixing the sheet metal.

​

The sheet metal is cut with millimetre precision using the integrated shear right from the first fixing. The BendTron can optionally be equipped with an electrical cutter. Fitting the clamping beam on the machine body eliminates constraining contours and force effects. Driven by a maintenance-free timing belt.

​

​

​

Each stand / tension arm unit is equipped with an electro-kinetically driven bending joint. The robust and rigid construction ensures an even bending capacity over the entire length. Thanks to the newly developed electro-kinetic drive, the bending process is faster and quieter than with hydraulically driven machines.

​

​

​

The BMS multi-touch control system enables intuitive operation by touching the screen. This ensures that new profiles can be created quickly or created using touchscreen painting. The control system can draw on stored profiles. Automatic bend sequence calculations with graphic simulation and illustration complete this all-rounder.

​

​

Choose from a range of very useful features:

​

• From the tablet to the machine

• Conical backgauge

• Insertion depth of 1250 mm

• Automatic clamping beam adjustment

• Non abrasive placement area

​

​

​
